V8.2 CUTTER
SHARE

V8.2 CUTTER

V8.2 CUTTER

V-8.2 CUTTER is the evolution of V8 model

V-8.2 CUTTER is a true bypass switching system, completely transparent, relay in silver/gold relays, with 8 programmable loops, plus 2 loops for send/ret cabling.

It’s possible to cable 5 pedals in front and 3 in s/r, or 6 in front and 2 in s/r. Any combination between loops and switch is possible.

The new model compared to old model V8:

 - 3 digits central display

-  MIDI advanced managing with Control Change, up to 3 chained to all programs

-  MIDI advanced managing with possibility to have up to 3 Program Change on different channels for each program

- Programmable Buffer assignable to very program

- MUTE function, activable "on fly"

- amp channel switch : latch, single shot, dual shot



V8.2 CUTTER
  • Ttrue bypass switching system
  • 8 programmable loops, plus 2 loops for send/ret cabling
  • It’s possible to cable 5 pedals in front and 3 in s/r, or 6 in front and 2 in s/r
  • 4 programmable switch for amps channel switch. Latch, singler shot or dual shot
  • Any combination between loops and switch is possible.
  • High dynamic buffer in input , programmable
  • 10 banks, 8 programs each, total 80 programs.
  • Up to 3 Program Change onu 3 channels on each program.
  • Up to 3 Control Change on each program
  • Possibility of direct access on loops, with MODE button Loops/programs
  • MIDI programming with MIDI MAPPING. It’s possible to assign program change 1/100 to any of 80 patch programs.
  • MIDI tap tempo with external switch, it’s possible to assign any control change 1/128 to external switch.
  • All programming operation might be done standing up, directly with V-8 buttons.
  • Tilted top and staggered button, for better access.
  • Dimension 34 cm x 12,5 cm high 6cm front 7cm back
